Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
15 data points
Operating Specifications
| Operating Weight | 49,318 lb |
|---|---|
| Fuel Capacity | 81.9 gal |
| Tire Size | 26.5R25 |
| Static Tipping Weight | 36,897 lb |
Engine
| Engine Model | e |
|---|---|
| Net Power | 260.2 hp |
Dimensions
| Ground Clearance | 23 in |
|---|---|
| Height - Top of Cab | 142 in |
| Wheelbase | 137 in |
| Reach at Max Lift and Dump | 43 in |
| Length with Bucket on Ground | 339 in |
Transmission
| Transmission Type | ZF 4WG260 |
|---|
Bucket
| Bucket Capacity - heaped | 5.00 yd³ |
|---|---|
| Dump Clearance at Max Raise | 130 in |
| Breakout Force | 52,156 lb |
