Caterpillar
BG210B
Asphalt Paver
14 specifications
Bitelli
BB651C
- Operating Weight w/ Screed
- 31,967 lb
- Paving Width - max
- 236 in
- Gross Power
- 94.0 hp
- Length w/ Screed
- 216 in
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight w/ Screed | 31,967 lb |
|---|---|
| Operating Weight w/o Screed | 22,730 lb |
| Fuel Capacity | 37.0 gal |
| Hydraulic System Fluid Capacity | 41.0 gal |
| Paving Width Minimum | 98 in |
| Paving Width Maximum | 236 in |
Engine
| Engine Model | Deutz F5L 914 |
|---|---|
| Gross Power | 94.0 hp |
Weights
| Operating Weight - With Extend-A-Mat 8-16B Screed | 31,967 lb |
|---|---|
| Operating Weight - With Screed | 31,967 lb |
| Tractor Weight | 22,730 lb |
Dimensions
| Transport Width | 100 in |
|---|---|
| Transport Height | 141 in |
| Length w/ Screed | 216 in |
| Width w/ Hopper Open | 124 in |
| Length - With Push Roller and Extend-a-Mat B Screed | 216 in |
| Track Contact Length | 93 in |
| Transport Height - Muffler Removed | 98 in |
Drive System
| Maximum Paving Speed | 1.2 mph |
|---|---|
| Maximum Travel Speed | 2.8 mph |
Hopper
| Hopper Capacity | 4,450 in |
|---|
Hopper/Paver
| Paving Width - max | 236 in |
|---|---|
| Paving Speed - max | 1.9 mph |
| Hopper Capacity | 7 lb |
| Travel Speed - max | 6.9 mph |
Service Refill Capacities
| Hydraulic Oil Tank | 41.0 gal |
|---|---|
| Fuel Tank Capacity | 37.0 gal |
| Cooling System | 8.0 gal |
Comparable machines
Other asphalt pavers in a similar weight class.
