Bobcat
ASV
PT-70
Compact Track Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 5,688 lb |
|---|---|
| Fuel Capacity | 7.1 gal |
| Hydraulic System Fluid Capacity | 5.3 gal |
| Cooling System Fluid Capacity | 1.3 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
| Engine Oil Capacity | 0.9 gal |
Engine
| Engine Model | D722-E3B-BC-6 |
|---|---|
| Displacement | 44 in³ |
| Power Measured @ | 3,600 rpm |
| Gross Power | 20.0 hp |
| Number of Cylinders | 3 |
| Torque Measured @ | 2,600 rpm |
| Engine Make | Kubota |
| Bore | 3 in |
| Stroke | 3 in |
| Peak Torque | 32 lb-ft |
Hydraulic System
| Pump Flow | 12.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,900 psi |
| Pump Type | Engine driven |
Dimensions
| Ground Clearance | 5 in |
|---|---|
| Overall Width | 36 in |
| Overall Height | 49 in |
| Length with Bucket | 94 in |
| Dump Height | 18 in |
| Length - without Bucket | 73 in |
| Dump angle | 50 ° |
| Hinge pin height, maximum height | 71 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|
Loader
| Breakout Force | — |
|---|---|
| Tipping Load | 1,601 lb |
