Bobcat
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Max Speed | 7.4 mph |
|---|---|
| Fuel Capacity | 24.8 gal |
| Hydraulic System Fluid Capacity | 9.6 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 90 A |
| Engine Oil Fluid Capacity | 2.3 gal |
| Chain Box Fluid Capacity - each side | 8.6 gal |
Engine
| Engine Model | V2403-MDI-E3B |
|---|---|
| Displacement | 148 in³ |
| Power Measured @ | 2,700 rpm |
| Gross Power | 48.9 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 117 lb-ft |
| Engine Make | Kubota |
| Stroke | 4 in |
| Bore | 4 in |
Hydraulic System
| Pump Flow Capacity | 17.1 gal/min |
|---|---|
| Relief Valve Pressure | 3,500 psi |
| Pump Type | Engine driven gear type |
| 3.8 | 3.8 s |
| Dump Time | 2.3 s |
| Lower Time | 2.5 s |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Height - Top of Cab | 78 in |
| Wheelbase | 43 in |
| Length with Bucket | 133 in |
| Length w/o Bucket | 106 in |
Loader
| Operating Load Rating | 1,850 lb |
|---|---|
| Operating Width | 65 in |
| Tipping load (ISO 14397) | 3,699 lb |
