Bobcat
ASV
PT-50
Compact Track Loader
29 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight | 5,202 lb |
|---|---|
| Max Speed - high range | 8.4 mph |
| Max Speed - low range | 5.2 mph |
| Fuel Capacity | 11.9 gal |
Engine
| Gross Power | 41.8 hp |
|---|---|
| Aspiration | Natural |
Hydraulic System
| Pump Flow | 12.5 gal/min |
|---|
Dimensions
| Height - Top of Cab | 74 in |
|---|---|
| Reach at Max Lift and Dump | 23 in |
| Width Over Tracks | 48 in |
| Length with Bucket | 118 in |
| Length - without Bucket | 90 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Length of Track on Ground | 52 in |
| Width of Track | 10 in |
Loader
| Tipping Angle | 3,190 ° |
|---|---|
| Operating Load | 1,595 lb |
| Operating Width | 50 in |
| Operating Load Rating | 1,100 lb |
