Bobcat
ASV
PT-70
Compact Track Loader
32 specifications
Bobcat
T190
- Operating Weight
- 7,612 lb
- Max Speed - high range
- 7.1 mph
- Displacement
- 122 in³
- Gross Power
- 61.0 hp
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 7,612 lb |
|---|---|
| Max Speed - high range | 7.1 mph |
| Fuel Capacity | 28.0 gal |
Engine
| Engine Model | V2003T |
|---|---|
| Displacement | 122 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 61.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
Hydraulic System
| Pump Flow | 16.3 gal/min |
|---|---|
| Relief Valve Pressure | 3,300 psi |
Dimensions
| Height - Top of Cab | 77 in |
|---|---|
| Reach at Max Lift and Dump | 31 in |
| Width Over Tracks | 66 in |
| Length with Bucket | 131 in |
| Clearance at Max Lift and Dump | 91 in |
| Turning Radius from Center - inc bucket | 79 in |
| Length - without Bucket | 102 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Length of Track on Ground | 55 in |
| Width of Track | 13 in |
| Number of Track Rollers per Side | 4 |
| Track Gauge | 54 in |
Loader
| Bucket Capacity | 0.60 yd³ |
|---|---|
| Tipping Angle | 6,851 ° |
| Operating Load | 1,900 lb |
| Operating Width | 68 in |
