Bobcat
ASV
PT-70
Compact Track Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 6,148 lb |
|---|---|
| Fuel Capacity | 17.3 gal |
| Travel Speed | 7.3 mph |
Engine
| Gross Power | 61.0 hp |
|---|---|
| Emission Tier Level | Tier 4 |
| Fuel | Diesel |
| Horsepower - Gross | 61.1 hp |
Hydraulic System
| Relief Valve Pressure | 3,300 psi |
|---|---|
| Auxiliary hydraulic flow | 16.7 gal/min |
Dimensions
| Height - Top of Cab | 78 in |
|---|---|
| Overall Width | 55 in |
| Reach at Max Lift and Dump | 24 in |
| Width Over Tracks | 12 in |
| Overall Height | 78 in |
| Length with Bucket | 127 in |
| Turning Radius from Center - machine rear | 7 in |
| Length - without Bucket | 98 in |
| Overall Track Length | 50 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Width of Track | 12 in |
General Specifications
| Operating Width IN. (CM) | 56.0 (142.2) Starting 2026 Model Year |
|---|---|
| Engine Power HP (KW) | 55 (41.0) Starting 2026 Model Year |
| OPERATING LOAD LBS. (KG) | 1,400 (635) Starting 2019 Model Year |
| Rated Operating Capacity LBS (KG) 50% | 1,400 (635) Starting 2020 Model Year |
| Narrow Track Operating Width IN. (CM)Roller or Torsion Suspension | NA Starting 2022 Model Year |
| Wide Track Operating Width IN. (CM)Roller or Torsion Suspension | NA Starting 2022 Model Year |
| Wide Track Operating Width IN. (CM) | NA Starting 2022 Model Year |
Loader
| Tipping Angle | 4,000 ° |
|---|---|
| Operating Load | 1,400 lb |
| Operating Width | 55 in |
