Bobcat
ASV
PT-70
Compact Track Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 7,557 lb |
|---|---|
| Fuel Capacity | 36.5 gal |
| Travel Speed | 7.1 mph |
Engine
| Gross Power | 66.0 hp |
|---|---|
| Emission Tier Level | Tier 4 |
| Fuel | Diesel |
| Horsepower - Gross | 66.0 hp |
Hydraulic System
| Relief Valve Pressure | 3,500 psi |
|---|---|
| Auxiliary hydraulic flow | 17.1 gal/min |
Dimensions
| Height - Top of Cab | 78 in |
|---|---|
| Overall Width | 67 in |
| Reach at Max Lift and Dump | 20 in |
| Overall Height | 78 in |
| Length with Bucket | 133 in |
| Turning Radius from Center - machine rear | 7 in |
| Length - without Bucket | 106 in |
| Overall Track Length | 55 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Width of Track | 13 in |
General Specifications
| Operating Width IN. (CM) | 67 (170.2) Starting 2019 Model Year |
|---|---|
| Engine Power HP (KW) | 68 (50.7) Starting 2022 Model Year |
| OPERATING LOAD LBS. (KG) | 1,995 (905) Starting 2019 Model Year |
| Rated Operating Capacity LBS (KG) 50% | 1,995 (905) Starting 2020 Model Year |
| Narrow Track Operating Width IN. (CM)Roller or Torsion Suspension | NA Starting 2022 Model Year |
| Wide Track Operating Width IN. (CM)Roller or Torsion Suspension | NA Starting 2022 Model Year |
| Wide Track Operating Width IN. (CM) | NA Starting 2022 Model Year |
Loader
| Tipping Angle | 5,700 ° |
|---|---|
| Operating Load | 1,995 lb |
| Operating Width | 67 in |
