Bobcat
ASV
PT-70
Compact Track Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 7,822 lb |
|---|---|
| Fuel Capacity | 36.5 gal |
| Cooling System Fluid Capacity | 3.0 gal |
| Engine Oil Capacity | 2.6 gal |
Engine
| Engine Model | V2607-DI-TE3B Interim Tier 4 |
|---|---|
| Displacement | 159 in³ |
| Power Measured @ | 2,700 rpm |
| Gross Power | 61.0 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,425 rpm |
| Stroke | 4 in |
| Bore | 4 in |
| Emission Tier Level | Tier 4 |
| Peak Torque | 156 lb-ft |
| Fuel | Diesel |
| Horsepower - Gross | 66.0 hp |
Hydraulic System
| Pump Flow | 17.1 gal/min |
|---|---|
| Relief Valve Pressure | 3,500 psi |
| Pump Type | Engine driven gear type |
Dimensions
| Height - Top of Cab | 78 in |
|---|---|
| Overall Width | 67 in |
| Reach at Max Lift and Dump | 20 in |
| Overall Height | 78 in |
| Length with Bucket | 133 in |
| Turning Radius from Center - machine rear | 7 in |
| Length - without Bucket | 106 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Length of Track on Ground | 55 in |
| Width of Track | 13 in |
General Specifications
| Operating Width IN. (CM) | 67 (170.2) Starting 2019 Model Year |
|---|---|
| Engine Power HP (KW) | 66 (49.2) Starting 2019 Model Year |
| OPERATING LOAD LBS. (KG) | 2,100 (953) Starting 2019 Model Year |
| Rated Operating Capacity LBS (KG) 50% | 2,100 (953) Starting 2020 Model Year |
Loader
| Tipping Angle | 6,000 ° |
|---|---|
| Operating Load | 2,100 lb |
| Breakout Force | — |
| Operating Width | 67 in |
