Caterpillar
239D
Compact Track Loader
65 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 1,900 lb |
|---|---|
| Fuel Capacity | 4.5 gal |
| Travel Speed | 3.5 mph |
Engine
| Gross Power | 22.0 hp |
|---|---|
| Engine Make | Kohler Command |
Hydraulic System
| Relief Valve Pressure | 3,000 psi |
|---|---|
| Auxiliary hydraulic flow | 9.4 gal/min |
| Hydraulic Reservoir | 16.0 gal |
Dimensions
| Ground Clearance | 5 in |
|---|---|
| Overall Height | 49 in |
| Length with Bucket | 94 in |
| Dump Height | 54 in |
| Length - without Bucket | 69 in |
| Dump angle | 34 ° |
| Width | 35 in |
| Hinge pin height - fully raised | 70 in |
Undercarriage
| Ground Pressure | 3 psi |
|---|
Loader
| Operating Load | 463 lb |
|---|---|
| Tip Capacity | 1,325 lb |
| Wheel (Track options) | 7 in |
