CaterpillarBoxer
322D
Compact Track Loader
20 specifications
1 / 5
Image 1 of 5
Specifications
65 data points
Operating Specifications
| Breakout Force - Tilt Cylinder | 3,969 lb |
|---|---|
| Tipping Load | 4,100 lb |
| Rated Operating Capacities - 35% Tipping Load | 1,435 lb |
| Rated Operating Capacities - 50% Tipping Load | 2,050 lb |
| Rated Operating Capacity with Optional Counterweight | 2,250 lb |
| Ground Contact Area - With 400 mm/15.7 in Track | 1,716 in³ |
| Ground Pressure - With 400 mm/15.7 in Track | 4 psi |
| Ground Contact Area - With 320 mm/12.6 in Track | 1,373 in³ |
| Ground Pressure - With 320 mm/12.6 in Track | 5 psi |
Engine
| Engine Model | Cat C2.2 CRDI |
|---|---|
| Displacement | 134 in³ |
| Gross Power | 60.0 hp |
| Net Power | 65.8 hp |
| Stroke | 4 in |
| Bore | 3 in |
| Gross Power - SAE J1995 | 67.1 hp |
| Net Power - ISO 9249 | 66.5 hp |
| Net Power - SAE 1349 | 65.8 hp |
| Peak Torque - 1,500 rpm - SAE J1995 | 1,836 in |
Hydraulic System
| Hydraulic Flow - Standard - Hydraulic Power (Calculated) | 35.5 hp |
|---|---|
| Hydraulic Flow - Standard - Loader Hydraulic Pressure | 3,336 psi |
| Hydraulic Flow - Standard - Loader Hydraulic Flow | 18.0 gal/min |
| Hydraulic Flow - High Flow - Hydraulic Power (Calculated) | 50.9 hp |
| Hydraulic Flow - High Flow - Loader Hydraulic Flow | 26.0 gal/min |
| Hydraulic Flow - High Flow - Loader Hydraulic Pressure | 3,336 psi |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 80 in |
| Length with Bucket on Ground | 127 in |
| Turning Radius from Center - machine rear | 57 in |
| Length - without Bucket | 99 in |
| Bucket Pin Height - Maximum Lift | 111 in |
| Maximum Overall Height | 144 in |
| Clearance at Maximum Lift and Dump | 81 in |
| Bucket Pin Height - Carry Position | 9 in |
| Reach - Maximum Lift/Dump | 22 in |
| Maximum Dump Angle | 50 ° |
| Departure Angle | 35 ° |
| Rack Back Angle - Maximum Height | 86 ° |
| Length - Track on Ground | 55 in |
| Overall Length - Track | 71 in |
| Turning Radius from Center - Coupler | 46 in |
| Maximum Reach - With Arms Parallel to Ground | 53 in |
| Turning Radius from Center - Bucket | 82 in |
| Vehicle Width (400 mm/15.7 in tracks) | 69 in |
| Vehicle Width (320 mm/12.6 in tracks) | 66 in |
Cab & Operator
| ROPS | ISO 3471:2008 |
|---|---|
| FOPS | ISO 3449:2005 Level I |
| FOPS Level II | ISO 3449:2005 Level II |
General Specifications
| Operating Width IN. (CM) | 66 (168) Starting 2019 Model Year |
|---|---|
| Engine Power HP (KW) | 67 (50) Starting 2019 Model Year |
| OPERATING LOAD LBS. (KG) | 2,050 (930) Starting 2016 Model Year |
| Rated Operating Capacity LBS (KG) 50% | 1,435 (651) Starting 2019 Model Year |
| Rated Operating Capacity LBS (KG) 35% | 1,435 (651) Starting 2020 Model Year |
Loader
| Operating Width | 66 in |
|---|---|
| Operating Load Rating | 2,050 lb |
Service Refill Capacities
| Cooling System | 3.2 gal |
|---|---|
| Hydraulic Tank | 9.0 gal |
| Fuel Tank | 15.1 gal |
| Engine Crankcase | 2.6 gal |
| Hydraulic System | 11.9 gal |
Air Conditioning System
| Air Conditioning | The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 0.81 kg of refrigerant which has a CO2 equivalent of 1.158 metric tonnes. |
|---|
Noise Level
| Inside Cab* | 83 dB(A) |
|---|---|
| Note (1) | Cab and Rollover Protective Structures (ROPS) are standard in North America and Europe. |
| Note (3) | ***The labeled sound power level for the CE marked configurations when measured according to the test procedure and conditions specified in 2000/14/EC. |
| Outside Cab** | 103 dB(A) |
