Case IH
John Deere
8RT 335
Tractor
17 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 29,000 lb |
|---|---|
| Fuel Capacity | 250.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 14,000 lb |
| 3 Point Hitch Type | III |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 16.6 gal |
| Hydraulic System Fluid Capacity | 26.0 gal |
| Engine Oil Capacity | 11.0 gal |
| Front Tire Size | 24.5-32 |
| Rear Tire Size | 24.5-32 |
Engine
| Engine Model | NTA-855 |
|---|---|
| Displacement | 854 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 375.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Engine Make | Cummins |
| PTO Power | 344.0 hp |
| Stroke | 6 in |
| Bore | 6 in |
| Torque | 1,266 lb-ft |
Hydraulic System
| Pump Flow Capacity | 26.0 gal/min |
|---|---|
| Number of Remote Control Valves | 4 |
| Relief Valve Pressure | 2,500 psi |
| Hydraulic System Type | Closed center load sensing pressure compensating |
Dimensions
| Height - Top of Cab | 165 in |
|---|---|
| Wheelbase | 142 in |
| Overall Length | 279 in |
| Width Outside Frame | 96 in |
Transmission
| Max Speed - Reverse | 8.6 mph |
|---|---|
| Max Speed - Forward | 17.3 mph |
| Number of Forward Gears | 12 |
| Transmission Type | Full power shift |
| Number of Reverse Gears | 3 |
Production
| Series | 9200 Series |
|---|---|
| Years Manufactured | 1,990 – 1,995 |
