Case IH
John Deere
8RT 335
Tractor
17 specifications
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Operating Weight | 28,720 lb |
|---|---|
| Fuel Capacity | 200.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 14,000 lb |
| 3 Point Hitch Type | III |
| Alternator Supplied Amperage | 125 A |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 16.6 gal |
| Engine Oil Capacity | 9.7 gal |
| Front Tire Size | 20.8R-38 |
| Rear Tire Size | 20.8R-38 |
Engine
| Engine Model | M11-A310 |
|---|---|
| Displacement | 659 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 310.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Engine Make | Cummins |
| PTO Power | 266.0 hp |
| Stroke | 6 in |
| Bore | 5 in |
Hydraulic System
| Pump Flow Capacity | 27.0 gal/min |
|---|---|
| Number of Remote Control Valves | 4 |
| Relief Valve Pressure | 2,900 psi |
| Hydraulic System Type | Closed center |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 144 in |
| Wheelbase | 137 in |
| Overall Length | 264 in |
| Width Outside Frame | 95 in |
| Front Axle Clearance | 32 in |
| Shipping weight | 29,599 lb |
| Rear axle clearance | 120 in |
Transmission
| Max Speed - Reverse | 9.4 mph |
|---|---|
| Max Speed - Forward | 19.3 mph |
| Number of Forward Gears | 12 |
| Transmission Type | Full power shift |
| Number of Reverse Gears | 3 |
Production
| Series | 9300 Series |
|---|---|
| Years Manufactured | 1,996 – 1,999 |
