Case IH

LBX332 Packer Cutter

Baler

Bale Width
31 in
Overall Width
102 in
Overall Height
120 in
All balers
Case IH LBX332 Packer Cutter Baler
1 / 5
Image 1 of 5
Image: messicks.com

Specifications

21 data points

Dimensions

Dimensions specifications
Overall Length333 in
Overall Width102 in
Overall Height120 in
Weight16,755 lb
Tractor PTO Power Required110.0 hp

Bale Size

Bale Size specifications
Bale Width31 in
Bale Length - max108 in
Bale Height33 in
Bale Length - min46 in

Baler Pickup

Baler Pickup specifications
Number of Bars4
Tine to Tine Width70 in
Number of Tines56
Lift Typehydraulic

Feeding Chamber

Feeding Chamber specifications
Packer Type3 forks 6 double tines
Stuffer Type6 tine

Plunger

Plunger specifications
SPM42
Stroke Length28 in
Bearing Type4 vertical 2 horizontal roller
Density Controlhydraulic

Wrapping System

Wrapping System specifications
Twine Ball Capacity30
Twine Type4 double knotter
