Case IH
MAGNUM 335
- Operating Weight
- 37,125 lb
- Displacement
- 543 in³
- Power Measured @
- 2,100 rpm
- Gross Power
- 330.0 hp
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 37,125 lb |
|---|---|
| Fuel Capacity | 180.2 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 18,898 lb |
| 3 Point Hitch Type | Cat. IVN/III |
| Alternator Supplied Amperage | 150 A |
| Cooling System Fluid Capacity | 6.5 gal |
| Hydraulic System Fluid Capacity | 45.5 gal |
| Engine Oil Capacity | 5.6 gal |
Engine
| Displacement | 543 in³ |
|---|---|
| Power Measured @ | 2,100 rpm |
| Gross Power | 330.0 hp |
| Aspiration | Wastegate Turbocharged / Air-to-Air |
| PTO Power | 275.0 hp |
| Torque Rise | 47.0 % |
Hydraulic System
| Pump Flow Capacity | 46.0 gal/min |
|---|---|
| Number of Remote Control Valves | 3 |
Dimensions
| Height - Top of Cab | 130 in |
|---|---|
| Wheelbase | 119 in |
| Tire Size | front 420/90R30 rear 520/85R42 |
Transmission
| Number of Forward Gears | 18 |
|---|---|
| Transmission Type | 18-speed full powershift |
| Number of Reverse Gears | 4 |
Production
| Series | Magnum Series |
|---|---|
| Years Manufactured | 2,008 – 2,011 |
Axles
| Axle Diameter | 5 in |
|---|---|
| Axle Length | 120 in |
