Case IH
PUMA 155
- Operating Weight
- 14,584 lb
- Displacement
- 409 in³
- Power Measured @
- 2,200 rpm
- Gross Power
- 155.0 hp
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 14,584 lb |
|---|---|
| Fuel Capacity | 79.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 12,185 lb |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 19.6 gal |
Engine
| Displacement | 409 in³ |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 155.0 hp |
| Number of Cylinders | 6 |
| Engine Make | CaseIH |
| PTO Power | 135.0 hp |
| Stroke | 5 in |
| Bore | 4 in |
Hydraulic System
| Pump Flow Capacity | 26.5 gal/min |
|---|---|
| Number of Remote Control Valves | — |
| Pump Type | Closed center pressure flow compensated |
Dimensions
| Wheelbase | 108 in |
|---|---|
| Height - Top of ROPS/FOPS | 119 in |
Transmission
| Number of Forward Gears | 18 |
|---|---|
| Transmission Type | Partial power shift |
| Number of Reverse Gears | 6 |
Production
| Series | Puma Series |
|---|---|
| Years Manufactured | 2,008 – 2,011 |
