Case IH
Gehl
2480
Baler
9 specifications
1 / 5
Image 1 of 5
Specifications
16 data points
Dimensions
| Tractor PTO Power Required | 60.0 hp |
|---|
Bale Size
| Bale Width | 48 in |
|---|---|
| Bale Diameter - max | 60 in |
| Bale Diameter - min | 36 in |
| Bale Weight - max | 1,200 lb |
| Bale Weight - min | 400 lb |
Baler Pickup
| Overall Width | 77 in |
|---|---|
| Number of Bars | 4 |
| Tine to Tine Width | 60 in |
| Number of Tines | 96 |
| Lift Type | dual-cam track |
Wrapping System
| Twine Ball Capacity | 6 |
|---|
Bale Chamber
| Number of Belts | 6 |
|---|---|
| Belt Width | 7 in |
| Number of Extension Springs | 1 |
| Number of Hydraulic Cylinders | 1 |
