Case IH
Gehl
2480
Baler
9 specifications
1 / 5
Image 1 of 5
Specifications
45 data points
Engine
| Number of hydraulic remote circuits | 1 or 2 |
|---|---|
| Tractor power | 40.3 hp |
Dimensions
| Overall Length | 163 in |
|---|---|
| Overall Width | 85 in |
| Overall Height | 101 in |
| Weight | 3,459 lb |
Tires & Wheels
| Standard | 11Lx14 6 ply |
|---|---|
| Option | 31x13.5-15 6 ply |
Bale Size
| Bale Width | 47 in |
|---|---|
| Bale Diameter - max | 60 in |
| Bale Diameter - min | 36 in |
| Bale Weight - max | 1,001 lb |
Baler Pickup
| Overall Width | 60 in |
|---|---|
| Number of Bars | 4 |
| Tine to Tine Width | 44 in |
| Number of Tines | 72 |
| Lift Type | single-cam track |
| Tine spacing | 3 in |
| Pickup gauge wheel | 1 standard; 2nd optional |
| Pickup lift | Manual: hydraulic field installed |
| Windguard description | 9 rods adjustable |
| Outer tine-to-tine width, standard | 45 in |
| Pickup working width | 61 in |
| Number of Tine Rows | 4 |
Wrapping System
| Twine Ball Capacity | 4 |
|---|---|
| Twine Type | Automatic electric |
| Netwrap, meshwrap feature | Optional |
Bale Chamber
| Number of Belts | 6 |
|---|---|
| Belt Width | 7 in |
| Number of Extension Springs | 2 |
| Bale chamber | Variable chamber |
| Bale ejector | Bale ramp spring-loaded |
| Belt description | 3-ply laced chevron |
| Forming mechanism_Belts | 6 |
| Forming mechanism_Rolls | 5 |
| Tensioning method | 1 extension spring 1 hydraulic cylinder |
Years of Manufacture
| First Entry Date | 1/27/2012 |
|---|---|
| Manufacturing Status | Current |
| Revision Date | 4/30/2017 |
Power Take-Off (PTO)
| PTO speed | 540 rpm |
|---|---|
| Drive | Shearbolt |
Sales Literature
| Document Date | 7/1/2015 |
|---|---|
| Document Number | HF-5148-15 |
| Literature Date | 42,430 |
| Literature Number | CIH03281601 |
