Case IH
John Deere
8RT 335
Tractor
17 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 51,000 lb |
|---|---|
| Fuel Capacity | 300.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 19,500 lb |
| 3 Point Hitch Type | IVN/III |
| Operating Voltage | 12 V |
| Drawbar Static Vertical Load Rating | 5,300 lb |
Engine
| Engine Model | QSX15 |
|---|---|
| Displacement | 915 in³ |
| Gross Power | 425.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Engine Make | Cummins |
| Stroke | 7 in |
| Bore | 5 in |
Hydraulic System
| Pump Flow Capacity | 40.0 gal/min |
|---|---|
| Hydraulic System Type | Pressure flow compensated |
Dimensions
| Wheelbase | 154 in |
|---|---|
| Front Axle Clearance | 5 in |
| Rear axle clearance | 5 in |
Transmission
| Number of Forward Gears | 16 |
|---|---|
| Transmission Type | Full power shift |
| Number of Reverse Gears | 2 |
