CaseZettelmeyer
ZL5001
Wheel Loader
35 specifications
Case
1221E
- Operating Weight
- 66,930 lb
- Bucket Capacity - heaped
- 6.61 yd³
- Gross Power
- 335.0 hp
- Net Power
- 320.0 hp
1 / 5
Image 1 of 5
Specifications
46 data points
Operating Specifications
| Operating Weight | 66,930 lb |
|---|---|
| Fuel Capacity | 124.2 gal |
| Tire Size | 29.5 x 25 |
| Hydraulic System Fluid Capacity | 89.9 gal |
| Static Tipping Weight | 55,830 lb |
| Operating Voltage | 24 V |
| Turning Radius | 300 in |
| Engine Oil Fluid Capacity | 9.8 gal |
| Rear Axle Oscillation | 26 ° |
| Alternator Supplied Amperage | 70 A |
| Front Axle/Diff Fluid Capacity | 15.9 gal |
| Rear Axle/Diff Fluid Capacity | 15.9 gal |
| Cooling System Fluid Capacity | 17.2 gal |
| Transmission Fluid Capacity | 11.4 gal |
| Rated Bucket Capacity | 9.19 yd³ |
Engine
| Engine Model | QSM11 |
|---|---|
| Displacement | 660 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 335.0 hp |
| Net Power | 320.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Make | Cummins |
| Torque Rise | 40.0 % |
Weights
| Operating Weight | 66,930 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 127.4 gal/min |
|---|---|
| Raise Time | 6.4 s |
| Lower Time | 3.0 s |
| Dump Time | 1.4 s |
| Relief Valve Setting | 2,990 psi |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 151 in |
| Wheelbase | 146 in |
| Width Over Tires | 130 in |
| Reach at Max Lift and Dump | 56 in |
| Length with Bucket on Ground | 381 in |
| Hinge Pin - Max Height | 180 in |
Transmission
| Max Speed - Forward | 21.1 mph |
|---|---|
| Max Speed - Reverse | 14.7 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 6.61 yd³ |
|---|---|
| Bucket Capacity - struck | 7.49 yd³ |
| Dump Clearance at Max Raise | 127 in |
| Bucket Width | 137 in |
