Hitachi
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 47,995 lb |
|---|---|
| Fuel Capacity | 97.8 gal |
| Tire Size | 26.5-25-20 PR L3 |
| Turning Radius | 229 in |
Engine
| Engine Model | 6D24TL |
|---|---|
| Displacement | 729 in³ |
| Power Measured @ | 2,100 rpm |
| Net Power | 266.0 hp |
Hydraulic System
| Raise Time | 6.4 s |
|---|---|
| Lower Time | 3.6 s |
| Dump Time | 1.5 s |
Dimensions
| Ground Clearance | 22 in |
|---|---|
| Height - Top of Cab | 137 in |
| Wheelbase | 134 in |
| Width Over Tires | 118 in |
| Reach at Max Lift and Dump | 50 in |
| Length with Bucket on Ground | 341 in |
| Hinge Pin - Max Height | 173 in |
Transmission
| Max Speed - Forward | 21.5 mph |
|---|---|
| Max Speed - Reverse | 22.7 mph |
| Transmission Type | 4-speed full powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 5.30 yd³ |
|---|---|
| Dump Clearance at Max Raise | 124 in |
| Breakout Force | 44,512 lb |
| Bucket Width | 125 in |
