Case

445

Skid Steer Loader

Operating Weight
7,677 lb
Bucket Capacity
0.71 yd³
Max Speed
11.7 mph
Gross Power
74.0 hp
All skid steer loaders
Case 445 Skid Steer Loader
1 / 5
Image 1 of 5
Image: brokentractor.com

Specifications

32 data points

Operating Specifications

Operating Specifications specifications
Operating Weight7,677 lb
Max Speed11.7 mph
Fuel Capacity17.3 gal
Hydraulic System Fluid Capacity11.0 gal
Tire Size12.00 x 16.5
Operating Voltage12 V
Alternator Supplied Amperage95 A
Engine Oil Fluid Capacity3.2 gal
Cooling System Fluid Capacity4.5 gal
Chain Box Fluid Capacity - each side2.0 gal

Engine

Engine specifications
Engine ModelFamily III 445/M2 Tier II certified
Displacement274 in³
Power Measured @2,300 rpm
Gross Power74.0 hp
Number of Cylinders4
Aspirationnaturally aspirated

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity21.0 gal/min
Relief Valve Pressure3,050 psi
Pump TypeGear

Dimensions

Dimensions specifications
Ground Clearance9 in
Height - Top of Cab80 in
Wheelbase46 in
Width Over Tires60 in
Reach at Max Lift and Dump32 in
Length with Bucket135 in
Clearance at Max Lift and Dump93 in
Turning Radius from Center - inc bucket83 in
Turning Radius from Center - machine rear86 in
Length w/o Bucket103 in

Loader

Loader specifications
Bucket Capacity0.71 yd³
Operating Load Rating2,500 lb
Tipping Angle5,000 °
