Case
Caterpillar
432D
Backhoe Loader
38 specifications
1 / 5
Image 1 of 5
Specifications
54 data points
Operating Specifications
| Operating Weight 4wd | 12,817 lb |
|---|---|
| Fuel Capacity | 31.4 gal |
| Hydraulic System Fluid Capacity | 33.0 gal |
| Cooling System Fluid Capacity | 4.4 gal |
| Tire Size Front - 2wd / 4wd | 11L x 16 10PR / 12 x 16.5 8PR |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 65 A |
| Transmission Fluid Capacity | 4.9 gal |
| Rear Axle Fluid Capacity | 3.9 gal |
| Front Axle Fluid Capacity | 1.5 gal |
Engine
| Engine Model | 4-390 |
|---|---|
| Displacement | 239 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 75.0 hp |
| Net Power | 71.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Engine Make | Case |
| Stroke | 5 in |
| Bore | 4 in |
| Net Max Torque | 193 lb-ft |
Hydraulic System
| Pump Flow Capacity | 28.5 gal/min |
|---|---|
| Relief Valve Pressure | 3,000 psi |
| Pump Type | Front mounted positive displacement gear-type tandem |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Wheelbase | 84 in |
| Transport Width | 86 in |
| Transport Length | 271 in |
| Height to Top of Suspended Cab | 98 in |
| Front Wheel Tread Width | 67 in |
| Rear Wheel Tread Width - min | 61 in |
Transmission
| Max Speed | 25.5 mph |
|---|---|
| Max Speed - Reverse | 30.8 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | Fully synchronized 4-speed forward reverse shuttle |
Tires & Wheels
| Rear Tires Size | 17.5L x 24 10PR / 19.5L x 24 10PR |
|---|
Backhoe
| Dig Depth | 170 in |
|---|---|
| Reach From Swivel | 205 in |
| Dig Depth - Extended | 219 in |
| Load Height - Extended | 159 in |
| Bucket Dig Force | 10,976 lb |
| Reach From Swivel - Extended | 253 in |
| Reach at Load Height - Extended | 134 in |
| Load Height | 134 in |
| Bucket Dig Force - Extended | 10,976 lb |
Loader
| Bucket Capacity | 1.10 yd³ |
|---|---|
| Lift Capacity | 1,951 lb |
| Clearance at Max Dump Height | 106 in |
| Bucket Breakout Force | 7,956 lb |
| Bucket Width | 82 in |
| Reach at Max Dump Height | 26 in |
| Dig Depth | 8 in |
