Mecalac
Caterpillar
434E
Backhoe Loader
37 specifications
.png)
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Operating Weight | 16,138 lb |
|---|---|
| Fuel Capacity | 37.0 gal |
| Cooling System Fluid Capacity | 4.5 gal |
| Operating Voltage | 12 V |
| Rear Axle Fluid Capacity | 4.6 gal |
| Front Axle Fluid Capacity | 1.9 gal |
Engine
| Engine Model | TCD 3.6 L4 |
|---|---|
| Displacement | 220 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 74.0 hp |
| Net Power | 69.9 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,300 rpm |
Hydraulic System
| Pump Flow Capacity | 22.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,626 psi |
Dimensions
| Dump angle | 45 ° |
|---|---|
| Hinge pin height, maximum height | 134 in |
| Reach @ ground level | 60,040 in |
| Loading height (EVW) | 125 in |
Transmission
| Max Speed | 24.0 mph |
|---|---|
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
General Specifications
| Operating Weight lbs (kg) | 16,138 (7,320) — Starting 2019 Model Year |
|---|---|
| Max Digging Depth ft. (m) | 17.10 (5.4) — Starting 2019 Model Year |
| Backhoe Loading Height ft. (m) | 13.8 (4.2) — Starting 2019 Model Year |
| Travel Speed 4th Gear Fwd MPH (kmh) | 24 (38) — Starting 2019 Model Year |
| Loader SAE HP (kw) | 74 (55) — Starting 2019 Model Year |
| Loader Lift Capacity lbs. (kg) | 8,287 (3,759) — Starting 2019 Model Year |
| Loader Breakout Force lbs. (kg) | 10,341 (4,691) — Starting 2019 Model Year |
Backhoe
| Dig Depth | 174 in |
|---|---|
| Reach From Swivel | 224 in |
| Load Height | 142 in |
Loader
| Bucket Capacity | 3,679.87 yd³ |
|---|---|
| Lift Capacity | 8,287 lb |
| Bucket Breakout Force | 9,442 lb |
