Case

821C

Wheel Loader

Operating Weight
37,901 lb
Bucket Capacity - heaped
3.60 yd³
Gross Power
204.0 hp
Net Power
186.0 hp
All wheel loaders
Case 821C Wheel Loader
1 / 5
Image 1 of 5
Image: brokentractor.com

Specifications

46 data points

Operating Specifications

Operating Specifications specifications
Operating Weight37,901 lb
Fuel Capacity70.8 gal
Tire Size23.5-25 L3
Hydraulic System Fluid Capacity46.0 gal
Static Tipping Weight30,082 lb
Operating Voltage24 V
Turning Radius227 in
Engine Oil Fluid Capacity5.6 gal
Rear Axle Oscillation24 °
Alternator Supplied Amperage65 A
Front Axle/Diff Fluid Capacity8.8 gal
Rear Axle/Diff Fluid Capacity7.1 gal
Cooling System Fluid Capacity8.5 gal
Transmission Fluid Capacity3.2 gal

Engine

Engine specifications
Engine Model6TAA-8304
Displacement504 in³
Power Measured @2,000 rpm
Gross Power204.0 hp
Net Power186.0 hp
Number of Cylinders6
Aspirationturbocharged and air to air cooled
Torque Measured @1,400 rpm
Torque Rise51.0 %

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity50.0 gal/min
Raise Time5.9 s
Lower Time4.3 s
Dump Time1.6 s
Relief Valve Setting2,814 psi
Pump Typedual vane-type tandem

Dimensions

Dimensions specifications
Ground Clearance17 in
Height - Top of Cab132 in
Wheelbase126 in
Width Over Tires107 in
Reach at Max Lift and Dump44 in
Length with Bucket on Ground295 in
Hinge Pin - Max Height156 in

Transmission

Transmission specifications
Max Speed - Forward23.5 mph
Max Speed - Reverse16.6 mph
Transmission Type4F/3R proportional w/ electronic control module torque sensing autoshift/manual shift and modulation
Number of Forward Gears4
Number of Reverse Gears3

Bucket

Bucket specifications
Bucket Capacity - heaped3.60 yd³
Bucket Capacity - struck3.10 yd³
Dump Clearance at Max Raise118 in
Breakout Force36,391 lb
Bucket Width109 in
