Case
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Fuel Capacity | 50.0 gal |
|---|---|
| Tire Size | 1400X24G2 |
| Hydraulic System Fluid Capacity | 29.0 gal |
| Operating Voltage | 24 V |
| Turning Radius | 391 in |
| Engine Oil Fluid Capacity | 3.0 gal |
| Rear Axle Oscillation | 24 ° |
| Alternator Supplied Amperage | 40 A |
| Front Axle/Diff Fluid Capacity | 4.5 gal |
| Rear Axle/Diff Fluid Capacity | 4.5 gal |
| Cooling System Fluid Capacity | 13.0 gal |
| Transmission Fluid Capacity | 9.0 gal |
Engine
| Engine Model | Case A401BD |
|---|---|
| Displacement | 401 in³ |
| Power Measured @ | 220 rpm |
| Gross Power | 114.0 hp |
| Net Power | 103.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,450 rpm |
| Stroke | 5 in |
| Bore | 4 in |
| Torque | 298 lb-ft |
| Air cleaner | Two element dry type |
Hydraulic System
| Raise Time | 6.1 s |
|---|---|
| Lower Time | 1.7 s |
| Dump Time | 3.5 s |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 125 in |
| Wheelbase | 108 in |
| Width Over Tires | 89 in |
| Reach at Max Lift and Dump | 84 in |
| Length with Bucket on Ground | 230 in |
| Hinge Pin - Max Height | 180 in |
Transmission
| Max Speed - Forward | 23.0 mph |
|---|---|
| Max Speed - Reverse | 9.5 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 1.80 yd³ |
|---|---|
| Bucket Capacity - struck | 1.50 yd³ |
| Dump Clearance at Max Raise | 110 in |
