Case
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
38 data points
Operating Specifications
| Fuel Capacity | 50.0 gal |
|---|---|
| Hydraulic System Fluid Capacity | 31.0 gal |
| Operating Voltage | 24 V |
| Engine Oil Fluid Capacity | 4.3 gal |
| Alternator Supplied Amperage | 40 A |
| Front Axle/Diff Fluid Capacity | 3.5 gal |
| Rear Axle/Diff Fluid Capacity | 3.5 gal |
| Cooling System Fluid Capacity | 13.0 gal |
| Transmission Fluid Capacity | 8.0 gal |
Engine
| Engine Model | A504BD |
|---|---|
| Displacement | 504 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 123.0 hp |
| Net Power | 110.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,400 rpm |
| Engine Make | Case |
| Stroke | 5 in |
| Bore | 5 in |
Hydraulic System
| Pump Flow Capacity | 48.1 gal/min |
|---|---|
| Raise Time | 6.1 s |
| Lower Time | 3.5 s |
| Dump Time | 1.7 s |
| Pump Type | Dual-Stage |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 124 in |
| Wheelbase | 108 in |
| Width Over Tires | 91 in |
| Reach at Max Lift and Dump | 39 in |
| Length with Bucket on Ground | 241 in |
| Hinge Pin - Max Height | 141 in |
Transmission
| Max Speed - Forward | 23.3 mph |
|---|---|
| Max Speed - Reverse | 9.7 mph |
| Transmission Type | Power Shift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 1.80 yd³ |
|---|---|
| Bucket Capacity - struck | 1.50 yd³ |
