Caterpillar
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 5,833 lb |
|---|---|
| Max Speed | 7.9 mph |
| Fuel Capacity | 17.2 gal |
| Hydraulic System Fluid Capacity | 14.6 gal |
| Tire Size | 10x16.5 6PR |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 85 A |
| Engine Oil Fluid Capacity | 2.2 gal |
| Cooling System Fluid Capacity | 2.7 gal |
| Chain Box Fluid Capacity - each side | 1.6 gal |
Engine
| Engine Model | 3024C T |
|---|---|
| Aspiration | turbocharged |
| Engine Make | Caterpillar |
Hydraulic System
| Pump Flow Capacity | 15.9 gal/min |
|---|---|
| Relief Valve Pressure | 3,336 psi |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 77 in |
| Wheelbase | 40 in |
| Width Over Tires | 61 in |
| Reach at Max Lift and Dump | 20 in |
| Length with Bucket | 128 in |
| Clearance at Max Lift and Dump | 86 in |
| Turning Radius from Center - inc bucket | 76 in |
| Turning Radius from Center - machine rear | 59 in |
| Length w/o Bucket | 100 in |
Loader
| Operating Load Rating | 1,499 lb |
|---|---|
| Tipping Angle | 2,998 ° |
| Breakout Force | 4,083 psi |
