Caterpillar
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
53 data points
Operating Specifications
| Operating Weight | 6,931 lb |
|---|---|
| Max Speed | 6.9 mph |
| Fuel Capacity | 17.2 gal |
| Hydraulic System Fluid Capacity | 14.6 gal |
| Operating Speed | 6.9 mph |
| Breakout Force - Tilt Cylinder | 4,056 lb |
| Rated Operating Capacity | 2,000 lb |
| Tipping Load | 4,000 lb |
| Rated Operating Capacity with Optional Counterweight | 2,047 lb |
| Breakout Force - Lift Cylinder | 3,814 lb |
Engine
| Engine Model | Cat 3034C |
|---|---|
| Displacement | 183 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 54.0 hp |
| Number of Cylinders | 4 |
| Engine Make | Caterpillar |
| Stroke | 4 in |
| Bore | 4 in |
| Net Flywheel Power | 54.0 hp |
Weights
| Operating Weight | 6,859 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 15.2 gal/min |
|---|---|
| Loader Hydraulic Pressure | 3,300 psi |
| Loader Hydraulic Flow | 15.1 gal/min |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Wheelbase | 46 in |
| Width Over Tires | 61 in |
| Reach at Max Lift and Dump | 30 in |
| Length with Bucket on Ground | 135 in |
| Length with Bucket | 135 in |
| Clearance at Max Lift and Dump | 90 in |
| Turning Radius from Center - inc bucket | 89 in |
| Length w/o Bucket | 110 in |
| Length - without Bucket | 109 in |
| Wheel Base | 43 in |
| Bucket Pin Height - Maximum Lift | 120 in |
| Maximum Overall Height | 155 in |
| Clearance at Maximum Lift and Dump | 88 in |
| Bucket Pin Height - Carry Position | 12 in |
| Reach - Maximum Lift/Dump | 30 in |
| Vehicle Width over Tires | 66 in |
| Bumper Overhang - Rear Axle | 39 in |
Cab & Operator
| FOPS | SAEJ/ISO 3449 APR98 Level I and ISO3449:1992 Level I |
|---|---|
| ROPS | SAE J1040 MAY94 and ISO3471:1994 |
| FOPS Level II | SAEJ/ISO 3449 APR 98 Level II and ISO 3449:1992 Level II (optional) |
Loader
| Bucket Capacity | 0.60 yd³ |
|---|---|
| Operating Load Rating | 2,000 lb |
| Tipping Angle | 3,770 ° |
Service Refill Capacities
| Cooling System | 24.0 gal |
|---|---|
| Hydraulic Tank | 9.2 gal |
| Fuel Tank | 18.2 gal |
| Chain Box - Each Side | 1.6 gal |
| Engine Crankcase | 2.1 gal |
| Hydraulic System | 15.3 gal |
