Caterpillar
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 7,566 lb |
|---|---|
| Max Speed | 7.7 mph |
| Fuel Capacity | 26.0 gal |
| Hydraulic System Fluid Capacity | 15.0 gal |
| Engine Oil Fluid Capacity | 2.6 gal |
| Cooling System Fluid Capacity | 3.7 gal |
| Chain Box Fluid Capacity - each side | 2.6 gal |
Engine
| Engine Model | 3044C DIT |
|---|---|
| Displacement | 201 in³ |
| Power Measured @ | 2,500 rpm |
| Number of Cylinders | 4 |
| Engine Make | Caterpillar |
Hydraulic System
| Pump Flow Capacity | 22.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,335 psi |
Dimensions
| Ground Clearance | 9 in |
|---|---|
| Height - Top of Cab | 83 in |
| Wheelbase | 49 in |
| Width Over Tires | 66 in |
| Reach at Max Lift and Dump | 24 in |
| Length with Bucket | 146 in |
| Clearance at Max Lift and Dump | 96 in |
| Turning Radius from Center - inc bucket | 96 in |
| Turning Radius from Center - machine rear | 58 in |
| Length w/o Bucket | 124 in |
Loader
| Bucket Capacity | 0.50 yd³ |
|---|---|
| Operating Load Rating | 2,350 lb |
| Tipping Angle | 4,700 ° |
| Operating Width | 66 in |
| Breakout Force | 7,328 psi |
