Caterpillar
ASV
RT-135 Forestry
Compact Track Loader
Specifications pending
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Breakout Force - Tilt Cylinder | 4,790 lb |
|---|---|
| Tipping Load | 7,030 lb |
| Rated Operating Capacities - 35% Tipping Load | 2,450 lb |
| Rated Operating Capacities - 50% Tipping Load | 3,500 lb |
| Ground Contact Area | 2,610 in³ |
| Ground Pressure | 4 psi |
| Breakout Force - Lift Cylinder | 4,882 lb |
Engine
| Engine Model | Cat 3034 Turbo Charged |
|---|---|
| Gross Power | 80.0 hp |
| Net Power | 74.0 hp |
| Stroke | 4 in |
| Bore | 4 in |
Service Refill Capacities
| Cooling System | 2.6 gal |
|---|---|
| Hydraulic Tank | 9.2 gal |
| Fuel Tank | 29.0 gal |
| Engine Crankcase | 1.8 gal |
| Hydraulic System | 13.5 gal |
Power Train
| Travel Speed Forward | 7.0 mph |
|---|---|
| Travel Speed Reverse | 7.0 mph |
