Caterpillar
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
21 data points
Engine
| Engine Model | Cat C4.2 ACERT |
|---|---|
| Displacement | 259 in³ |
| Gross Power | 96.6 hp |
| Net Power | 89.9 hp |
| Bore | 4 in |
| Stroke | 5 in |
| Flywheel Power | 89.9 hp |
Hydraulic System
| Maximum Pressure - Swing | 3,336 psi |
|---|---|
| Maximum Pressure - Travel | 5,076 psi |
| Pilot System - Maximum Flow | 5.8 gal/min |
| Pilot System - Maximum Pressure | 598 psi |
Drive System
| Maximum Drawbar Pull | 25,628 lb |
|---|
Service Refill Capacities
| Cooling System | 4.7 gal |
|---|---|
| Hydraulic System - Including Tank | 42.8 gal |
| Final Drive - Each | 0.8 gal |
| Engine Oil | 5.2 gal |
| Hydraulic Tank | 39.6 gal |
| Swing Drive | 0.8 gal |
| Fuel Tank | 66.0 gal |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|---|
| Swing Torque | 22,828 lb-ft |
