Caterpillar
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
23 data points
Engine
| Engine Model | Cat C4.4 ACERT |
|---|---|
| Displacement | 270 in³ |
| Net Power | 97.0 hp |
| Stroke | 5 in |
| Bore | 4 in |
| Flywheel Power | 97.0 hp |
Hydraulic System
| Maximum Pressure - Swing | 3,340 psi |
|---|---|
| Maximum Pressure - Travel | 5,080 psi |
| Maximum Pressure - Equipment | 4,420 psi |
| Pilot System - Maximum Flow | 4.8 gal/min |
| Pilot System - Maximum Pressure | 600 psi |
| Main System - Maximum Flow (total) | 67.0 gal/min |
Boom/Stick Excavator Option 1
| Max Digging Depth | 234 in |
|---|---|
| Max Reach Along Ground | 342 in |
Drive System
| Maximum Drawbar Pull | 25,400 lb |
|---|---|
| Maximum Travel Speed | 3.4 mph |
Service Refill Capacities
| Cooling System | 7.4 gal |
|---|---|
| Hydraulic System - Including Tank | 42.3 gal |
| Final Drive - Each | 0.8 gal |
| Hydraulic Tank | 22.2 gal |
| Fuel Tank Capacity | 47.0 gal |
Swing
| Swing Speed | 12 rpm |
|---|---|
| Swing Torque | 22,790 lb-ft |
