Caterpillar
Kobelco
140SR
Excavator
4 specifications
1 / 5
Image 1 of 5
Specifications
63 data points
Engine
| Engine Model | Cat 3126B ATAAC HEUI Fuel System |
|---|---|
| Net Power | 173.0 hp |
| Bore | 4 in |
| Stroke | 5 in |
| Net Power - ISO 9249 | 168.0 hp |
| Net Power - SAE J1349 | 166.0 hp |
| Net Power - EEC 80/1269 | 168.0 hp |
Weights
| Operating Weight - Standard Undercarriage | 53,352 lb |
|---|
Hydraulic System
| Maximum Pressure - Swing | 3,553 psi |
|---|---|
| Maximum Pressure - Travel | 4,980 psi |
| Boom Cylinder - Bore | 5 in |
| Boom Cylinder - Stroke | 51 in |
| Main Implement System - Maximum Flow (2x) | 58.1 gal/min |
| Maximum Pressure - Equipment | 4,980 psi |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 119 in |
| Length of Track on Ground | 151 in |
| Tail Swing Radius | 119 in |
| Width to Outside of Tracks | 126 in |
| Digging Depth | 276 in |
| Digging Reach | 276 in |
Undercarriage
| Track Gauge | 102 in |
|---|---|
| Max Travel Speed | 3.5 mph |
| Shoe Size | 32 in |
| Drawbar Pull | 50,132 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 168 in |
|---|---|
| Max Reach Along Ground | 381 in |
| Max Loading Height | 312 in |
| Max Vertical Wall Digging Depth | 128 in |
| Max Cutting Height | 443 in |
| Shipping Length of Unit | 409 in |
| Shipping Height of Unit | 121 in |
Bucket
| Reference Bucket Capacity | 1.60 yd³ |
|---|---|
| Maximum Bucket Capacity | 2.50 yd³ |
| Minimum Bucket Capacity | 0.71 yd³ |
Drive System
| Maximum Drawbar Pull | 50,132 lb |
|---|
Service Refill Capacities
| Cooling System | 10.0 gal |
|---|---|
| Hydraulic System - Including Tank | 64.7 gal |
| Final Drive - Each | 1.3 gal |
| Engine Oil | 9.0 gal |
| Fuel Tank Capacity | 132.0 gal |
| Swing Drive | 2.1 gal |
Boom/Stick Excavator Option 2
| Max Digging Depth | 183 in |
|---|---|
| Max Vertical Wall Digging Depth | 144 in |
| Max Cutting Height | 455 in |
| Max Loading Height | 332 in |
| Max Reach Along Ground | 396 in |
| Shipping Length of Unit | 401 in |
| Shipping Height of Unit | 121 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 200 in |
|---|---|
| Max Cutting Height | 470 in |
| Max Loading Height | 348 in |
| Max Vertical Wall Digging Depth | 159 in |
| Max Reach Along Ground | 414 in |
| Shipping Length of Unit | 400 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 233 in |
|---|---|
| Max Cutting Height | 494 in |
| Max Reach Along Ground | 444 in |
| Max Loading Height | 388 in |
| Max Vertical Wall Dig Depth | 197 in |
| Shipping Length of Unit | 391 in |
Standards
| Brakes | SAE J1026 APR90 |
|---|---|
| Cab/FOGS | SAE J1356 FEB88 ISO 10262 |
