Caterpillar
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Fuel Capacity | 158.6 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 169.1 gal/min |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
Engine
| Engine Model | 3176CATAAC |
|---|---|
| Displacement | 629 in³ |
| Net Power | 290.0 hp |
Dimensions
| Tail Swing Radius | 143 in |
|---|
Undercarriage
| Track Gauge | 108 in |
|---|---|
| Max Travel Speed | 2.8 mph |
| Shoe Size | 30 in |
| Drawbar Pull | 72,400 lb |
Boom/Stick Excavator Option 1
| Max Loading Height | 304 in |
|---|---|
| Shipping Height of Unit | 145 in |
Boom/Stick Excavator Option 2
| Max Loading Height | 296 in |
|---|---|
| Shipping Height of Unit | 145 in |
Boom/Stick Excavator Option 3
| Shipping Length of Unit | 463 in |
|---|
Boom/Stick Excavator Option 5
| Max Digging Depth | 280 in |
|---|---|
| Max Reach Along Ground | 420 in |
| Max Cutting Height | 401 in |
| Max Loading Height | 263 in |
| Max Vertical Wall Dig Depth | 222 in |
| Shipping Height of Unit | 152 in |
| Shipping Length of Unit | 449 in |
Boom/Stick Excavator Option 6
| Max Digging Depth | 264 in |
|---|---|
| Max Reach Along Ground | 420 in |
| Max Cutting Height | 401 in |
| Max Loading Height | 263 in |
| Max Vertical Wall Dig Depth | 197 in |
| Shipping Length of Unit | 449 in |
| Shipping Height of Unit | 152 in |
