936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Fuel Capacity | 190.3 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 203.0 gal/min |
| Hydraulic System Fluid Capacity | 150.6 gal |
| Hydraulic System Relief Valve Pressure | 5,076 psi |
| Engine Oil Capacity | 11.4 gal |
| Cooling System Fluid Capacity | 13.3 gal |
| Swing Drive Fluid Capacity | 2.7 gal |
Engine
| Engine Model | C13 ACERT |
|---|---|
| Displacement | 763 in³ |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 127 in |
| Length of Track on Ground | 212 in |
| Tail Swing Radius | 149 in |
| Removal Counterweight Clearance | 50 in |
Undercarriage
| Track Gauge | 108 in |
|---|---|
| Max Travel Speed | 4.7 mph |
| Shoe Size | 36 in |
| Number of Shoes per Side | 52 |
| Drawbar Pull | 75,311 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 352 in |
|---|---|
| Max Reach Along Ground | 510 in |
| Max Loading Height | 311 in |
| Max Vertical Wall Digging Depth | 256 in |
| Max Cutting Height | 441 in |
| Shipping Length of Unit | 489 in |
| Shipping Height of Unit | 144 in |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 323 in |
|---|---|
| Max Vertical Wall Digging Depth | 318 in |
| Max Cutting Height | 424 in |
| Max Loading Height | 294 in |
| Max Reach Along Ground | 478 in |
| Shipping Length of Unit | 469 in |
| Shipping Height of Unit | 144 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 301 in |
|---|---|
| Max Cutting Height | 426 in |
| Max Loading Height | 294 in |
| Max Vertical Wall Digging Depth | 227 in |
| Max Reach Along Ground | 462 in |
| Shipping Length of Unit | 466 in |
| Shipping Height of Unit | 141 in |
