CaterpillarCaterpillar
651E
Scraper
98 specifications
1 / 5
Image 1 of 5
Specifications
91 data points
Engine
| Displacement | 1,099 in³ |
|---|---|
| Net Power | 490.0 hp |
| Bore | 5 in |
| Stroke | 6 in |
| Tractor Engine | 3408E |
| Gross Power - Gears 1-2 | 475.0 hp |
| Net Power - Gears 1-2 | 450.0 hp |
| Net Power - Gears 3-8 | 490.0 hp |
Weights
| Front Axle | 72,051 lb |
|---|---|
| Front Axle Weight - Loaded | 99,236 lb |
| Rear Axle | 40,529 lb |
| Rear Axle - Weight - Loaded | 95,344 lb |
| Scraper Shipping | 64,958 lb |
| Total Shipping | 111,158 lb |
| Tractor Shipping | 46,200 lb |
Hydraulic System
| Bowl Cylinder Bore | 7 in |
|---|---|
| Bowl Cylinder Stroke | 20 in |
| Ejector Cylinder Stroke | 61 in |
| Ejector Cylinder Bore | 7 in |
| Scraper Circuit | 91.0 gal/min |
| Steering Circuit | 103.0 gal/min |
| Relief Valve - Steering Circuit | 1,960 psi |
| Cushion Hitch Circuit | 9.0 gal/min |
| Relief Valve - Implement Circuit | 2,500 psi |
| Compensator Settings - Cushion Hitch Circuit | 2,300 psi |
| Compensator Settings - Elevator Circuit | 5,300 psi |
| Floor Cylinder Bore | 6 in |
| Floor Cylinder Stroke | 52 in |
| Supplemental Steering Circuit | 77.0 gal/min |
Dimensions
| Height - Top of Cab | 146 in |
|---|---|
| Wheelbase | 355 in |
| Overall Length | 583 in |
| Overall Width | 156 in |
| Overall Height | 168 in |
| Wheel Base | 355 in |
| Width - Outside Rear Tires | 143 in |
| Height - Scraper Blade Maximum | 18 in |
| Height - Overall Shipping | 167 in |
| Length - Overall Machine | 583 in |
| Width - Overall Machine | 160 in |
| Width - Inside of Bowl | 134 in |
| Rear Axle - Rear of Machine | 96 in |
| Front of Tractor to Front Axle | 132 in |
| Width - Rear Tire Center Lines | 97 in |
| Width - Tractor | 137 in |
Transmission
| Max Speed - Forward | 33.0 mph |
|---|---|
| 1 Forward | 3.0 mph |
| 2 Forward | 5.3 mph |
| 3 Forward | 7.4 mph |
| 4 Forward | 10.1 mph |
| 5 Forward | 13.5 mph |
| 6 Forward | 18.3 mph |
| Reverse | 6.2 mph |
| 7 Forward | 24.7 mph |
| 8 Forward | 33.4 mph |
Service Refill Capacities
| Cooling System | 33.0 gal |
|---|---|
| Fuel Tank | 215.0 gal |
| Final Drive - Each | 7.0 gal |
| Crankcase | 11.7 gal |
| Transmission | 33.0 gal |
| Differential | 36.0 gal |
| Hydraulic Reservoir | 50.0 gal |
| Wheel Coolant - Each | 19.5 gal |
Steering System
| Steering Angle - Left | 85 ° |
|---|---|
| Steering Angle - Right | 90 ° |
| Width - 180 degrees Turn | 481 in |
| Hydraulic Output | 96.2 gal/min |
| Ground-Driven Secondary Steering System | 52.0 gal/min |
Bowl
| Heaped Capacity | 34.10 yd³ |
|---|---|
| Width of Cut | 138 in |
| Max Depth of Cut | 24 in |
| Rated Payload | 82,012 lb |
| Struck Capacity | 23.20 yd³ |
Scraper Engine
| Displacement | 49,673 in³ |
|---|
Tractor Engine
| Net Power | 450.0 hp |
|---|---|
| Gross Power | 490.0 hp |
| Displacement | 1,099 in³ |
Scraper Bowl
| Rated Load | 82,000 lb |
|---|---|
| Capacity - Struck | 23.20 yd³ |
| Depth of Spread - Maximum | 23 in |
| Ground Clearance - Maximum | 20 in |
| Depth of Cut - Maximum | 17 in |
| Scraper Capacity - Heaped | 33.99 yd³ |
| Width - Cut - To Router Bits | 12 in |
| Cutting Edge Thickness | 1 in |
| Hydraulic Penetration Force | 87,608 lb |
Elevator
| Number of Flights | 14 |
|---|---|
| Length - Flights | 114 in |
| Length - Overall | 177 in |
| Spacing of Flights | 24 in |
| Width - Flight Face | 10 in |
