CaterpillarCaterpillar
773G
Off-Highway Truck
12 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Fuel Capacity | 851.1 gal |
|---|---|
| Tire Size | 37.00R57 (E-4) |
Engine
| Engine Model | 3516 |
|---|---|
| Displacement | 4,217 in³ |
| Gross Power | 1,800.0 hp |
| Net Power | 1,705.0 hp |
Weights
| Empty Weight | 268,792 lb |
|---|---|
| Loaded Weight | 699,880 lb |
| Weight Distribution Front - loaded | 33.0 % |
| Weight Distribution Rear - loaded | 67.0 % |
| Weight Distribution Front - empty | 47.0 % |
| Weight Distribution Rear - empty | 53.0 % |
Dimensions
| Wheelbase | 226 in |
|---|---|
| Overall Length | 480 in |
| Overall Width | 289 in |
| Overall Height | 243 in |
| Dump Height | 469 in |
Transmission
| Max Speed | 33.6 mph |
|---|---|
| Number of Gears - Forward | 6 |
General Specifications
| Operating Weight lbs (kg) | 715,000 (324,319) — Starting 2024 Model Year |
|---|---|
| Engine type | Cat 3516E — Starting 2024 Model Year |
| Articulated/Rigid | Rigid — Starting 2024 Model Year |
| Drive Configuration | 2WD — Starting 2024 Model Year |
| Rated Payload Tons (Metric Tons) | 213 (193.2) — Starting 2024 Model Year |
| Mfg. Model | 789 — Starting 2024 Model Year |
| Planetary Powershift Transmission | Auto — Starting 2024 Model Year |
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 389,957.5 gal |
|---|
Dump
| Rated Payload | 390,000 lb |
|---|---|
| Load Capacity - heaped | 137.40 yd³ |
| Load Capacity - Struck | 95.49 yd³ |
