Terex
Caterpillar
773G
Off-Highway Truck
12 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Fuel Capacity | 599.9 gal |
|---|---|
| Tire Size | 33.00R51 |
| Engine Oil Capacity | 58.2 gal |
| Cooling System Fluid Capacity | 120.0 gal |
| Hydraulic System Fluid Capacity | 214.8 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 100 A |
Engine
| Engine Model | 12 V 4000 |
|---|---|
| Gross Power | 1,725.0 hp |
| Net Power | 1,570.0 hp |
| Number of Cylinders | 12 |
| Aspiration | 100 amps |
| Rated Engine Speed | 215 rpm |
Weights
| Empty Weight | 248,900 lb |
|---|---|
| Loaded Weight | 548,900 lb |
| Weight Distribution Front - loaded | 33.5 % |
| Weight Distribution Rear - loaded | 66.5 % |
| Weight Distribution Front - empty | 52.6 % |
| Weight Distribution Rear - empty | 47.4 % |
Dimensions
| Wheelbase | 209 in |
|---|---|
| Overall Length | 485 in |
| Overall Width | 280 in |
| Overall Height | 252 in |
| Dump Height | 426 in |
| Dump Ground Clearance | 44 in |
Transmission
| Max Speed | 39.8 mph |
|---|
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 299,967.3 gal |
|---|
Dump
| Dump Angle | 45 ° |
|---|---|
| Raise Time | 20.0 s |
| Lower Time | 9.0 s |
| Load Capacity - heaped | 117.79 yd³ |
| Load Capacity - Struck | 77.20 yd³ |
