773G
Off-Highway Truck
12 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Fuel Capacity | 760.0 gal |
|---|---|
| Tire Size | 40R57(6) |
| Engine Oil Capacity | 52.9 gal |
| Cooling System Fluid Capacity | 130.0 gal |
| Hydraulic System Fluid Capacity | 234.9 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 175 A |
Engine
| Engine Model | 12V4000 |
|---|---|
| Gross Power | 2,025.0 hp |
| Net Power | 1,875.0 hp |
| Number of Cylinders | 12 |
| Aspiration | 175 amps |
| Rated Engine Speed | 235 rpm |
Weights
| Empty Weight | 330,000 lb |
|---|---|
| Loaded Weight | 740,000 lb |
| Weight Distribution Front - loaded | 32.4 % |
| Weight Distribution Rear - loaded | 67.6 % |
| Weight Distribution Front - empty | 46.4 % |
| Weight Distribution Rear - empty | 53.6 % |
Dimensions
| Wheelbase | 221 in |
|---|---|
| Overall Length | 516 in |
| Overall Width | 288 in |
| Overall Height | 272 in |
| Dump Height | 473 in |
| Dump Ground Clearance | 64 in |
Transmission
| Max Speed | 40.4 mph |
|---|
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 409,955.3 gal |
|---|
Dump
| Dump Angle | 45 ° |
|---|---|
| Raise Time | 22.0 s |
| Lower Time | 14.0 s |
| Load Capacity - heaped | 160.89 yd³ |
| Load Capacity - Struck | 120.40 yd³ |
