Euclid
R85B
Off-Highway Truck
39 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Fuel Capacity | 699.9 gal |
|---|---|
| Tire Size | 33.00 51 |
| Cooling System Fluid Capacity | 60.0 gal |
| Hydraulic System Fluid Capacity | 108.0 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 175 A |
| Brake/Hoist System Fluid Capacity | 34.0 gal |
Engine
| Engine Model | 12V-149TIB |
|---|---|
| Power Measured @ | 1,900 rpm |
| Gross Power | 1,350.0 hp |
| Net Power | 1,279.0 hp |
| Number of Cylinders | 12 |
Weights
| Empty Weight | 210,100 lb |
|---|---|
| Loaded Weight | 510,000 lb |
Dimensions
| Ground Clearance | 25 in |
|---|---|
| Wheelbase | 203 in |
| Overall Length | 449 in |
| Overall Width | 252 in |
| Overall Height | 426 in |
| Dump Height | 203 in |
| Dump Ground Clearance | 60 in |
Transmission
| Max Speed | 33.4 mph |
|---|
Dump
| Rated Payload | 299,829 lb |
|---|---|
| Dump Angle | 45 ° |
| Raise Time | 22.0 s |
| Lower Time | 13.0 s |
| Load Capacity - heaped | 100.79 yd³ |
| Load Capacity - Struck | 70.69 yd³ |
