Terex
TA27
Off-Highway Truck
46 specifications
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Fuel Capacity | 265.0 gal |
|---|---|
| Tire Size | 24.00-49(48)E-3 |
| Engine Oil Capacity | 37.0 gal |
| Cooling System Fluid Capacity | 71.0 gal |
| Hydraulic System Fluid Capacity | 104.0 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 75 A |
| Steering System Fluid Capacity | 30.0 gal |
| Diff and Final Drive Fluid Capacity | 39.0 gal |
| Brake/Hoist System Fluid Capacity | 74.0 gal |
Engine
| Engine Model | KT38-C |
|---|---|
| Displacement | 2,300 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 925.0 hp |
| Net Power | 865.0 hp |
| Number of Cylinders | 12 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 3,020 lb-ft |
Weights
| Empty Weight | 132,000 lb |
|---|---|
| Loaded Weight | 315,300 lb |
| Weight Distribution Front - loaded | 33.0 % |
| Weight Distribution Rear - loaded | 67.0 % |
Dimensions
| Ground Clearance | 24 in |
|---|---|
| Wheelbase | 182 in |
| Overall Length | 404 in |
| Overall Width | 215 in |
| Overall Height | 202 in |
| Dump Height | 380 in |
| Dump Ground Clearance | 30 in |
Transmission
| Max Speed | 33.6 mph |
|---|---|
| Transmission Type | Allison DP-8963 Planetary |
| Number of Gears - Forward | 6 |
| Number of Gears - Reverse | 1 |
Dump
| Rated Payload | 188,054 lb |
|---|---|
| Raise Time | 13.0 s |
| Lower Time | 17.0 s |
| Load Capacity - heaped | 67.10 yd³ |
| Load Capacity - Struck | 46.60 yd³ |
