Caterpillar
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
17 data points
Operating Specifications
| Fuel Capacity | 185.0 gal |
|---|---|
| Tire Size | 21x35 2 ** Radials |
Engine
| Engine Model | 3412E HEUI |
|---|---|
| Gross Power | 683.0 hp |
Weights
| Empty Weight | 88,860 lb |
|---|---|
| Weight Distribution Front - loaded | 33.0 % |
| Weight Distribution Rear - loaded | 67.0 % |
Dimensions
| Overall Length | 364 in |
|---|---|
| Overall Width | 166 in |
| Overall Height | 149 in |
| Dump Height | 261 in |
Transmission
| Max Speed | 35.6 mph |
|---|---|
| Number of Gears - Forward | 8 |
| Number of Gears - Reverse | 2 |
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 115,987.4 gal |
|---|
Dump
| Rated Payload | 116,000 lb |
|---|---|
| Load Capacity - heaped | 41.70 yd³ |
Comparable machines
Other off-highway trucks in a similar weight class.
