TerexTerex
33-11C
Off-Highway Truck
19 specifications
1 / 5
Image 1 of 5
Specifications
46 data points
Operating Specifications
| Fuel Capacity | 103.1 gal |
|---|---|
| Tire Size | 23.5R25 |
| Engine Oil Capacity | 5.8 gal |
| Cooling System Fluid Capacity | 14.6 gal |
| Hydraulic System Fluid Capacity | 53.4 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 70 A |
| Transmission Fluid Capacity | 16.7 gal |
Engine
| Engine Model | QSM 11 |
|---|---|
| Displacement | 660 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 365.0 hp |
| Net Power | 335.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 1,234 lb-ft |
| Make | Cummins |
Weights
| Operating Weight | 103,395 lb |
|---|---|
| Total Empty | 48,280 lb |
| Front Axle - empty | 25,240 lb |
| Total Loaded | 103,395 lb |
| Rear Axle - empty | 11,640 lb |
| Front Axle - loaded | 34,435 lb |
| Rear Axle - loaded | 34,635 lb |
| Center Axle - empty | 11,400 lb |
| Center Axle - loaded | 34,325 lb |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Wheelbase | 199 in |
| Overall Length | 386 in |
| Overall Width | 88 in |
| Overall Height | 143 in |
| Dump Height | 236 in |
| Dump Ground Clearance | 29 in |
Transmission
| Max Speed | 31.4 mph |
|---|---|
| Transmission Type | ZF 6WG 260 RPC fully automatic |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 3 |
Drive System
| Drive Config | 6x6 |
|---|
Articulating/Rigid
| Articulating/Rigid | Articulated |
|---|
Dump
| Rated Payload | 55,115 lb |
|---|---|
| Dump Angle | 65 ° |
| Raise Time | 12.0 s |
| Lower Time | 7.5 s |
| Capacity - Heaped | 20.30 yd³ |
| Capacity - Struck | 16.40 yd³ |
