Hydrema
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
46 data points
Operating Specifications
| Fuel Capacity | 80.0 gal |
|---|---|
| Tire Size | 3240 |
| Engine Oil Capacity | 6.7 gal |
| Hydraulic System Fluid Capacity | 53.0 gal |
| Alternator Supplied Amperage | 70 A |
| Transmission Fluid Capacity | 24.0 gal |
Engine
| Engine Model | Cummings QSB |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 264.0 hp |
| Net Power | 274.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 990 lb-ft |
| Make | Cummins |
Weights
| Operating Weight | 78,264 lb |
|---|---|
| Total Empty | 35,540 lb |
| Front Axle - empty | 17,630 lb |
| Total Loaded | 44,070 lb |
| Rear Axle - empty | 8,600 lb |
| Front Axle - loaded | 23,800 lb |
| Rear Axle - loaded | 27,550 lb |
| Center Axle - empty | 8,600 lb |
| Center Axle - loaded | 27,550 lb |
Dimensions
| Ground Clearance | 228 in |
|---|---|
| Wheelbase | 1,752 in |
| Overall Length | 139 in |
| Overall Width | 108 in |
| Overall Height | 137 in |
Transmission
| Max Speed | 31.0 mph |
|---|---|
| Transmission Type | ZF Ergopower 6 WG 210 |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 3 |
General Specifications
| Operating Weight lbs (kg) | 35,540 (16,120) Starting 2016 Model Year |
|---|---|
| Engine type | Cummins QSB, 6.7 EPA Tier IVi Turbo Diesel Starting 2016 Model Year |
| Articulated/Rigid | A Starting 2016 Model Year |
| Drive Configuration | 6x6 Starting 2016 Model Year |
| Rated Payload Tons (Metric Tons) | 22 (20) Starting 2016 Model Year |
| Drive System Mech/Electr. | M Starting 2016 Model Year |
Drive System
| Drive Config | 6x6 |
|---|
Articulating/Rigid
| Articulating/Rigid | Articulated |
|---|
Dump
| Rated Payload | 48,502 lb |
|---|---|
| Dump Angle | 72 ° |
| Raise Time | 7.5 s |
| Lower Time | 5.5 s |
| Capacity - Heaped | 15.70 yd³ |
| Capacity - Struck | 11.60 yd³ |
