Caterpillar
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Fuel Capacity | 59.4 gal |
|---|---|
| Engine Oil Fluid Capacity | 4.4 gal |
| Front Axle/Diff Fluid Capacity | 5.5 gal |
| Rear Axle/Diff Fluid Capacity | 5.5 gal |
| Transmission Fluid Capacity | 6.1 gal |
| Rated Bucket Capacity | 2.69 yd³ |
| Engine Oil Capacity | 4.0 gal |
| Static Tipping Load - Bucket | 17,916 lb |
| Front Diff Fluid Capacity | 5.6 gal |
| Rear Diff Fluid Capacity | 5.6 gal |
| Static Tipping Load - Forks | 13,669 lb |
Engine
| Engine Model | C6.6 |
|---|---|
| Displacement | 403 in³ |
| Power Measured @ | 2,300 rpm |
| Gross Power | 138.0 hp |
| Number of Cylinders | 6 |
| Max Torque | 496 lb-ft |
| Make | Cat |
Hydraulic System
| Relief Valve Setting | 3,755 psi |
|---|---|
| Pump Type | Implement Pump |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 127 in |
| Wheelbase | 110 in |
| Width Over Tires | 98 in |
| Hinge Pin - Max Height | 154 in |
| Length w/ Bucket on Ground | 282 in |
| Dump Clearance at Max Lift | 111 in |
| Reach at Max Height and Dump | 40 in |
| Max Lift Height | 144 in |
| Fork Tine Length | 49 in |
| Length with out Forks on Ground | 300 in |
Transmission
| Max Speed - Forward | 23.9 mph |
|---|---|
| Max Speed - Reverse | 13.5 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Dump Clearance at Max Raise | 111 in |
|---|---|
| Bucket Width | 101 in |
