Caterpillar
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Rated Bucket Capacity | 2.50 – 6.50 yd³ |
|---|
Engine
| Net Power | 148.0 hp |
|---|---|
| Make | Cat |
General Specifications
| Net Power | 168.00 hp (125.28 kw) Starting 2023 Model Year |
|---|---|
| Operating Weight | 28,183.00 lbs (12,783.61 kg) Starting 2023 Model Year |
| Operating Weight lbs (kg) | 28,770 (13,050) Starting 2016 Model Year |
| Bucket Capacity | 2.7 cu yd Starting 2023 Model Year |
| Bucket Capacity cu. yd. (cu m) | 2.5 - 5.0 (1.9 - 3.8) Starting 2016 Model Year |
| Engine type | Cat C7.1 Starting 2021 Model Year |
| Engine Power | 153 (114) Starting 2019 Model Year |
| Max Dump Height | 9.60 ft (2.93 m) Starting 2021 Model Year |
| Max Dump Height ft.( m) | 3.3 (1.0) Starting 2016 Model Year |
| Travel Speed(Fwd/Rev) | 25 / 25 mph Starting 2021 Model Year |
| Engine Power HP (KW) | 153 (114) Starting 2016 Model Year |
| Tip Load | 19,383 (8,792) Starting 2021 Model Year |
| Engine | C7.1 Starting 2023 Model Year |
| Breakout Force | 28,404.00 lbs ft (38,510.14 nm) Starting 2023 Model Year |
| Full-Turn Tipping Load | 16,752.00 lbs (7,598.59 kg) Starting 2023 Model Year |
| Rated Bucket Capacity | 2.5.5.0 cu yd Starting 2021 Model Year |
