Caterpillar
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
15 data points
General Specifications
| Net Power | 230.00 hp (171.51 kw) — Starting 2021 Model Year |
|---|---|
| Operating Weight | 42,557.00 lbs (19,303.55 kg) — Starting 2021 Model Year |
| Operating Weight lbs (kg) | 42,357 (19,213) — Starting 2016 Model Year |
| Bucket Capacity | 3.1.4.2 cu yd — Starting 2021 Model Year |
| Bucket Capacity cu. yd. (cu m) | 3.3 - 12.0 (2.5 - 9.2) — Starting 2016 Model Year |
| Engine type | Cat C7.1 — Starting 2021 Model Year |
| Engine Power | 230 (172) — Starting 2019 Model Year |
| Max Dump Height | 9.4 (2.9) — Starting 2019 Model Year |
| Max Dump Height ft.( m) | 4.7 (1.4) — Starting 2016 Model Year |
| Travel Speed(Fwd/Rev) | 24.9 / 16.0 mph — Starting 2021 Model Year |
| Engine Power HP (KW) | 230 (172) — Starting 2016 Model Year |
| Tip Load | 28,144 (12,766) — Starting 2021 Model Year |
| Engine | C7.1 ACERT — Starting 2021 Model Year |
| Breakout Force | 40,320.00 lbs ft (54,665.86 nm) — Starting 2021 Model Year |
| Full-Turn Tip Load | 25,962.00 lbs (11,776.18 kg) — Starting 2021 Model Year |
