Caterpillar
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Rated Bucket Capacity | 3.30 – 11.99 yd³ |
|---|
Engine
| Net Power | 250.0 hp |
|---|---|
| Make | Cat |
General Specifications
| Net Power | 250.00 hp (186.43 kw) — Starting 2021 Model Year |
|---|---|
| Operating Weight | 44,591.00 lbs (20,226.16 kg) — Starting 2021 Model Year |
| Operating Weight lbs (kg) | 44,712 (20,281) — Starting 2016 Model Year |
| Bucket Capacity | 3.1.4.2 cu yd — Starting 2021 Model Year |
| Bucket Capacity cu. yd. (cu m) | 3.3 - 12.0 (2.5 - 9.2) — Starting 2016 Model Year |
| Engine type | Cat C7.1 — Starting 2021 Model Year |
| Engine Power | 250 (186) — Starting 2019 Model Year |
| Max Dump Height | 10.0 (3.0) — Starting 2019 Model Year |
| Max Dump Height ft.( m) | 4.7 (1.4) — Starting 2016 Model Year |
| Travel Speed(Fwd/Rev) | 24.9 / 16.0 mph — Starting 2021 Model Year |
| Engine Power HP (KW) | 250 (186) — Starting 2016 Model Year |
| Tip Load | 29,877 13,552) — Starting 2021 Model Year |
| Engine | C7.1 ACERT — Starting 2021 Model Year |
| Breakout Force | 42,889.00 lbs ft (58,148.91 nm) — Starting 2021 Model Year |
| Full-Turn Tip Load | 27,494.00 lbs (12,471.08 kg) — Starting 2021 Model Year |
