Caterpillar
963 LGP
- Operating Weight
- 41,092 lb
- Bucket Capacity - heaped
- 2.69 yd³
- Bucket Capacity - struck
- 2.20 yd³
- Net Power
- 150.2 hp
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 41,092 lb |
|---|---|
| Bucket Capacity - heaped | 2.69 yd³ |
| Bucket Capacity - struck | 2.20 yd³ |
| Max Speed | 6.3 mph |
| Fuel Capacity | 69.0 gal |
| Static Tipping Load | 27,165 lb |
| Breakout Force Bucket | 38,227 lb |
| Hydraulic System Fluid Capacity | 15.9 gal |
Engine
| Engine Model | 3304 |
|---|---|
| Displacement | 427 in³ |
| Net Power | 150.2 hp |
Hydraulic System
| Lower Time | 2.3 s |
|---|---|
| Raise Time | 6.2 s |
| Dump Time | 1.3 s |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 131 in |
| Width to Outside of Tracks | 95 in |
| Length with Bucket on Ground | 251 in |
| Reach at Dump Height | 47 in |
| Clearance at Full Height and Dump | 124 in |
Undercarriage
| Length of Track on Ground | 97 in |
|---|---|
| Track Gauge | 73 in |
| Track Shoe Width | 22 in |
| Ground Pressure | 10 psi |
| Number of Track Rollers per Side | 6 |
| Ground Contact Area | 4,185 in³ |
